Prediction of Delay-Free Scene for Quadruped Robot Teleoperation: Integrating Delayed Data with User Commands

Seunghyeon Ha1, Seongyong Kim1, Soo-Chul Lim*,1,
1Dongguk University
*Corresponding Author
Our research has been accepted for publication in IEEE Robotics and Automation Letters (RA-L) and has also been accepted for an oral/poster presentation at IROS 2025.
Paper Video Code

Abstract

Teleoperation systems are utilized in various controllable systems, including vehicles, manipulators, and quadruped robots. However, during teleoperation, communication delays can cause users to receive delayed feedback, which reduces controllability and increases the risk faced by the remote robot.

To address this issue, we propose a delay-free video generation model based on user commands that allows users to receive real-time feedback despite communication delays. Our model predicts delay-free video by integrating delayed data (video, point cloud, and robot status) from the robot with the user's real-time commands. The LiDAR point cloud data, which is part of the delayed data, is used to predict the contents of areas outside the camera frame during robot rotation. We constructed our proposed model by modifying the transformer-based video prediction model VPTR-NAR to effectively integrate these data.

For our experiments, we acquired a navigation dataset from a quadruped robot, and this dataset was used to train and test our proposed model. We evaluated the model's performance by comparing it with existing video prediction models and conducting an ablation study to verify the effectiveness of its utilization of command and point cloud data.

Video

Framework

System Framework

The proposed model predicts delay-free visual feedback on user commands by integrating delayed data (video, point cloud, robot status) transmitted from the remote robot with the user’s real-time commands.

With the proposed model, delay-free visual feedback to user commands can be predicted in a quadruped robot teleoperation system with communication delays.

Network Architecture

The network is primarily composed of three encoders — an image encoder, a point cloud encdoer, and a robot-command encoder — followed by a video transformer.

  • The Image, Point Cloud, and Robot-Cmd encoders extract distinct features from their respective input data.
  • The Video Transformer plays a key role by fusing all extracted features to predict the representation of current video frames.
  • The Image Decoder converts the predicted features into final RGB images that can be visually interpreted.
Network Architecture

Results

Comparison of Qualitative result with other baselines. This result is in the form of a prediction for a scenario where the robot turns left after moving straight forward.

comparison_baselines

Table: comparison with other models

table

Ablation Study

Qualitative result of command data manipulation. Each prediction is the result of using the same input frame and different commands (turning left, moving forward and turning right).
Command Result
Qualitative result of point cloud data manipulation. The point cloud used in each prediction is as follows: (a) the original data, (b) the maximum values and (c) the minimum values of the LiDAR measurement range.
Point Cloud Result

Qualitative result of varied scenarios. (a) and (b) represent the same location, as do (c) and (d). While each pair depicts the same location, the model successfully generated the newly introduced structures when they were present.

Scenario Result
